Cable Joint Stand APU2.0

Product No: S13-1291

Cable Joint Stand APU2.0

Cable Joint Stand APU2.0 is an adjustable stand for medium- and high-voltage cable joints and terminations.

Quick Links

£816.92 ex VAT

£980.30 inc VAT

Product Wishlist & Compare Placeholder

Free Standard Delivery over £100

Delivery cost calculated at checkout.

Quick Links

Full description

The Cable Joint Stand APU2.0 is an adjustable stand for medium- and high-voltage cable joints and terminations. It supports the cables during jointing and termination work and helps keep the working position stable, controlled and ergonomic.

Each cable clamp is individually adjustable, with stepless lateral and tilt-angle adjustment. Cables can also be secured when entering vertically from the ground. The wide height adjustment range allows working from approximately 200 mm up to 1300 mm.

The legs can be configured as a three- or four-leg setup, making the stand suitable for different joint bays and trench conditions. The legs rotate 180°, allowing the stand to be positioned directly over a cable trench. The clamps are designed for MV and HV cables with outer diameters from 18 to 90 mm.

Product Information:
