QuelStop QB50D Fire Batt 1200 x 600 x 50mm

Product No: S00-9308

QuelStop QB50D Fire Batt 1200 x 600 x 50mm

QB50 QuelStop Ablative Coated Mineral Wool Fire Batt is a coated mineral wool board used to reinstate the fire rating of wall and floor constructions where they have been penetrated by services.

Quick Links

£34.61 ex VAT

£41.53 inc VAT

Product Wishlist & Compare Placeholder

Free Standard Delivery over £100

Delivery cost calculated at checkout.

Quick Links

Full description

Standards & Approvals:

• Up to 2 hour fire rating
• Suitable for use in flexible walls, rigid walls and floors
• Suitable for use around cables, cable bunches, cable trays, cable ladders and non-combustible pipes
• Also suitable for use around plastic pipes and insulated non-combustible pipes with the addition of other Quelfire products
• Can be used as a blank seal as a head of wall detail
• Can be installed into both lined and unlined apertures in partition walls
• Can be installed as a single or double batt seal
• Can be pattress fitted / face fixed to walls
• Tested with plasterboard ceilings and steel composite profile decks
• Can be used in conjunction with Intufoam to allow for deflection head movement

Application

QuelStop Fire Batt is used to maintain the fire integrity of compartment walls or floors, typically where oversized holes have been formed for services. A single or double batt may be required depending on a number of factors and it can also be fitted as a pattress fit (or face fit).

QuelStop Fire Batt is always installed in conjunction with QuelStop Intumescent Acrylic Sealant which is applied to all cuts, joints and exposed edges.

Where combustible, non-combustible and insulated services penetrate the QuelStop Fire Batt seal, the following additional products may be required:
• QuelCoil Intuwrap
• QWR Fire Collar
• QRS Fire Sleeve
• QuelStop HPE Graphite Sealant
• QuelStop Intumescent Acrylic Sealant
• QIF Insulated Fire Sleeve
• QI Intufoam
