TDUX Inflatable Duct Seals - Pack of 10

TDUX is a unique inflatable wraparound duct sealing system for permanently sealing telephone cable ducts in order to prevent the leakage of water from the duct into exchange vaults or manholes.

Suitable for use with plastic, concrete or steel ducting wall-feedthrough systems.
Can be used with polyethylene or lead-jacketed cables.
Various sizes available for sealing a wide range of ducts and cables.

Supplied in a pack of 10.

See datasheet for further details and selection table.

Specifications

TDUX-60 Inflatable Duct Seal Size 60 PK10

Dimensions
Width 120 mm
Length 262 mm
Cable Diameter, maximum 45 mm
Cable Diameter, minimum 18 mm
Conduit Inner Diameter, maximum 60 mm
Conduit Inner Diameter, minimum 45 mm

TDUX-90 Inflatable Duct Seal Size 90 (Duct Seal 1A) Pk10

Width: 120 mm
Length: 422 mm
Cable Diameter: Maximum 90 mm
Cable Diameter: Minimum 45 mm
Conduit Inner Diameter: Maximum 110 mm
Conduit Inner Diameter: Minimum 75 mm

TDUX-100 Inflatable Duct Seal Size 100 PK10

Dimensions
Width: 120 mm
Length: 482 mm
Cable Diameter: Maximum 90 mm
Cable Diameter: Minimum 45 mm
Conduit Inner Diameter: Maximum 110 mm
Conduit Inner Diameter: Minimum 75 mm

TDUX-125 Inflatable Duct Seal Size 125 PK10

Dimensions
Width: 120 mm
Length: 567 mm
Cable Diameter: Maximum 103 mm
Cable Diameter: Minimum 83 mm
Conduit Inner Diameter: Maximum 125 mm
Conduit Inner Diameter: Minimum 110 mm

BT Openreach References

TDUX-90 (Duct Seal 1A) - Ref 074835

Mills / CommScope Part Numbers

TDUX-60-INT-PK10 TDUX-60 Inflatable Duct Seal Size 60 Pk10
TDUX-90-INT-PK10 TDUX-90 Inflatable Duct Seal Size 90 (Duct Seal 1A) Pk10
TDUX-100-INT-PK10 TDUX-100 Inflatable Duct Seal Size 100 Pk10
TDUX-125-INT-PK10 TDUX-125 Inflatable Duct Seal Size 125 Pk10
