Tempo NETcat Pro2 Wiring Tester

The NETcat® Pro2 is a digital tool for fast, accurate checking of cables, wiring and network service.

Operated using a back-lit touch screen display, the NETcat® Pro2 tests wiring continuity and proper pair allocation, measures the length of cables, determines if network service is available and identifies Power over Ethernet (PoE) cables.

Using a fingertip or the built-in stylus, the screen can be used to control and display a range of tests from fault finding to TDR length measurement.

Available in the following options:

Tempo NETcat Pro Wiring Tester

Tempo NETcat Pro Wiring Tester Kit with Remotes and Case

Product Features

Touch screen display with contrast adjustment and backlight
Tests shielded twisted pair (STP) unshielded twisted pair (UTP) and coaxial cables
0-2000 foot cable length via TDR
Generate four distinct, precision tones for tracing low-loss cables like Cat 5
Identifies active network devices (PC or Hub) on 10/100 Base-T networks
Displays network device capabilities
Patch cable and remote jack wire-map.
Detects shorts, opens, reversed, crossed and split pairs
Office identificationusing remote ID units
Troubleshoots and verifies a wide range of networks
Graphical touch-screen display
Remote jack ID and verification
Operates on a single 9V battery, with low battery indicator
Pulsed time domain reflectometer(TDR) shows length of all pairs
Compatible with Tempo precision digital probes


Specifications

Dimensions: 3.3” x 1.4” x 6.7”(8.5 cm x 3.5 cm x 17 cm)
Weight: 0.45 lb. (200 g)
Power Requirements: 9V Alkaline Battery (PP3)
Display LCD: Dot Pixels: 128 x 128 dots
Viewing Area: 60.0 x 58.4
Backlight: White LED
Buttons: LCD touch-screen, single momentary contact push button
Operating Temperature: 0°C to 50°C
Storage Temperature: -20°C to 70°C
Interface Connections: RJ45 shielded jacks, F-type  threaded female coaxial connectors

TDR Calibrations:User selectable based on a known cable length. Range: 50 to 2,000 ft. - 40% to 100% in step of 1%.
Length: 2,000 ft. Maximum
Resolution: 1 ft.
Accuracy to Open/Short: +4% or 2 ft. - whichever is greater
Remote Identifier: 2,000 ft. (609.6 meters) maximum distance
Wiremap: 358 ft. (100 meters) maximum distance
Memo Pad Size: 60 Characters
NVP Library-Twisted Pair Cables: 5 fixed and 5 user definable
NVP Library-COAX Cables: 5 fixed and 5 user definable

Mills Part Numbers

C00-1328 Tempo NETcat Pro2 NC-500 Structured Wiring Troubleshooter

C00-1329 Tempo NETcat Pro NC-520 Structured Wiring Troubleshooter Kit with Remotes
