Mills Water Meter Isolation Clamp

The Mills Water Meter Isolation Clamp, is a security device which clamps into most round water pipe stop chambers with diameters of 150mm to 210mm, preventing assess to the stop cock or water meter. This consequently cuts off the water supply to the premise and prevents reconnection of a temporarily disconnected water supply.

 The clamp is manufactured from precision ground anodised aluminium components with a steel plated tamper proof adjusting screw

The clamp utilises three expandable legs with radiused and serrated teethed shoulders , that clamp and lock into chamber wall using the tamper proof locking key (provided).

Operation

The clamp is lowered into the round water chamber using the locating tee key (supplied), then opened and secured into wall of the chamber using the tamper proof locking key (supplied)

Removing of the clamp is the reversal of the installation procedure

Contents

-Mills Water Meter Isolation Clamp

-Locating key (475mm long)

-Tamperproof Locking Key (675mm)
