Toby Box - 300 X 100 X 160mm - Unbranded - Black

The TOBYBOX300 has been designed by HellermannTyton with a mounting point for the Customer Entry Point (CEP) Enclosure.
The hinged lid opens up to a 105˚ angle for easy access and should be installed to open towards the customer home.
If some resurface work occurs and buries the toby box, a metal detector can be used to detect it, as a metal washer has been fitted within the lid. A Torx security screw prevents from vandalism.
Each side features knock out circles for two different size ducts: 14mm diameter or 53mm diameter. A drainage hole can be drilled at the base to evacuate excess water.
The TOBYBOX300 is manufactured from non-slip black polypropylene and is 100% recycled and recyclable. This is a lightweight underground access chamber, easy to install with a ribbed design for strength.
A 67mm x 35mm inset position on the front lid allows for a customer logo to be moulded.
It has been tested to BS 5834-2-2011 Class to sustain a 5kN load and its installation should be in compliance with local rules and guidance.

Features & benefits:

Mounting point for Customer Entry Point
Self-venting
Narrow profile with a 300mm depth
Contoured base to rest on top of Duct 56
Secured lid with a 105˚ angle
Suitable for ducts from 14mm to 53mm OD
Sustains a 5kN load BS 5834-2-2011
Includes drainage hole
