Fibre Optic Patch Cord Singlemode Duplex - OS2

OS2 singlemode fibre optic patch cords are used to connect longer distance networks, between buildings and campuses and in long-distance metropolitan and access telecoms and CATV networks.

All assemblies are fully tested prior to delivery and supplied with test result.

OS2 singlemode patch cords are supplied using 3mm (for additional ruggedising) cable with a yellow LSZH cable jacket as standard.

Applications

• Data Centres

• LAN/Enterprise

• Metropolitan and access networks

• FTTH

• CATV

• Transmission, switch and test equipment

Features

•  LSZH - Low smoke zero halogen, yellow jacket

• 900μm tight buffer, 3mm simplex and duplex cable

• Supplied with UPC polished connector end face as standard

• OS2 fibre conforms to or exceeds all relevant ISO/IEC, TIA/EIA and ITU standar

Fibre Specification

Attenuation (db / km)≤ 0.32 @ 1310nm / ≤ 0.18 @ 1550m

Chromatic Dispersion (ps/nm=km)1285 - 1340 ≥ -3.4 ≤ 3.41550nm ≤ 181625nm ≤ 22Zero

Dispersion Wavelength (nm)1312 ± 22

Cable Specification

Cable Material LSZH

Strength Member Aramid

Crush (N/100mm) 1000

Tensile (N) 120

Operating temperature (°C) -20 to 60

Connector Specification

IL Max/Master (db) (Acceptance)≤ 0.25

Av./Random (db)≤ 0.20

Return Loss ≥ 55

Colour: Yellow

Mills Part Numbers

T70-2292 FC-FC Singlemode Duplex Patch Cord OS2 9/125 1m
T70-2293 FC-FC Singlemode Duplex Patch Cord OS2 9/125 2m
T70-2294 FC-FC Singlemode Duplex Patch Cord OS2 9/125 3m
T70-2295 FC-FC Singlemode Duplex Patch Cord OS2 9/125 5m
T70-2296 FC-FC Singlemode Duplex Patch Cord OS2 9/125 10m

T70-0117 FC-LC Singlemode Duplex Patch Cord OS2 9/125 1m
T70-0118 FC-LC Singlemode Duplex Patch Cord OS2 9/125 2m
T70-0119 FC-LC Singlemode Duplex Patch Cord OS2 9/125 3m
T70-0120 FC-LC Singlemode Duplex Patch Cord OS2 9/125 5m
T70-0121 FC-LC Singlemode Duplex Patch Cord OS2 9/125 10m

T70-0122 FC-SC Singlemode Duplex Patch Cord OS2 9/125 1m
T70-0123 FC-SC Singlemode Duplex Patch Cord OS2 9/125 2m
T70-0124 FC-SC Singlemode Duplex Patch Cord OS2 9/125 3m
T70-0125 FC-SC Singlemode Duplex Patch Cord OS2 9/125 5m
T70-0126 FC-SC Singlemode Duplex Patch Cord OS2 9/125 10m

T70-2302 LC-LC Singlemode Duplex Patch Cord OS2 9/125 1m
T70-2303 LC-LC Singlemode Duplex Patch Cord OS2 9/125 2m
T70-2304 LC-LC Singlemode Duplex Patch Cord OS2 9/125 3m
T70-2305 LC-LC Singlemode Duplex Patch Cord OS2 9/125 5m
T70-2306 LC-LC Singlemode Duplex Patch Cord OS2 9/125 10m

T70-2307 LC-SC Singlemode Duplex Patch Cord OS2 9/125 1m
T70-2308 LC-SC Singlemode Duplex Patch Cord OS2 9/125 2m
T70-2309 LC-SC Singlemode Duplex Patch Cord OS2 9/125 3m
T70-2310 LC-SC Singlemode Duplex Patch Cord OS2 9/125 5m
T70-2311 LC-SC Singlemode Duplex Patch Cord OS2 9/125 10m

T70-2317 LC-ST Singlemode Duplex Patch Cord OS2 9/125 1m
T70-2318 LC-ST Singlemode Duplex Patch Cord OS2 9/125 2m
T70-2319 LC-ST Singlemode Duplex Patch Cord OS2 9/125 3m
T70-2320 LC-ST Singlemode Duplex Patch Cord OS2 9/125 5m
T70-2321 LC-ST Singlemode Duplex Patch Cord OS2 9/125 10m

T70-2297 SC-SC Singlemode Duplex Patch Cord OS2 9/125 1m
T70-2298 SC-SC Singlemode Duplex Patch Cord OS2 9/125 2m
T70-2299 SC-SC Singlemode Duplex Patch Cord OS2 9/125 3m
T70-2300 SC-SC Singlemode Duplex Patch Cord OS2 9/125 5m
T70-2301 SC-SC Singlemode Duplex Patch Cord OS2 9/125 10m

T70-0127 ST-SC Singlemode Duplex Patch Cord OS2 9/125 1m
T70-0128 ST-SC Singlemode Duplex Patch Cord OS2 9/125 2m
T70-0129 ST-SC Singlemode Duplex Patch Cord OS2 9/125 3m
T70-0130 ST-SC Singlemode Duplex Patch Cord OS2 9/125 5m
T70-0131 ST-SC Singlemode Duplex Patch Cord OS2 9/125 10m

T70-0410 SC/APC - LC Singlemode Duplex Patch Cord OS2 9/125 1m
T70-0411 SC/APC - LC Singlemode Duplex Patch Cord OS2 9/125 2m
T70-0412 SC/APC - LC Singlemode Duplex Patch Cord OS2 9/125 3m
T70-0413 SC/APC - LC Singlemode Duplex Patch Cord OS2 9/125 5m
T70-0414 SC/APC - LC Singlemode Duplex Patch Cord OS2 9/125 10m

T70-0390 SC/APC - SC Singlemode Duplex Patch Cord OS2 9/125 1m
T70-0393 SC/APC - SC Singlemode Duplex Patch Cord OS2 9/125 2m
T70-0394 SC/APC - SC Singlemode Duplex Patch Cord OS2 9/125 3m
T70-0408 SC/APC - SC Singlemode Duplex Patch Cord OS2 9/125 5m
T70-0409 SC/APC - SC Singlemode Duplex Patch Cord OS2 9/125 10m

T70-0382 SC/APC - SC/APC Singlemode Duplex Patch Cord OS2 9/125 1m
T70-0384 SC/APC - SC/APC Singlemode Duplex Patch Cord OS2 9/125 2m
T70-0386 SC/APC - SC/APC Singlemode Duplex Patch Cord OS2 9/125 3m
T70-0387 SC/APC - SC/APC Singlemode Duplex Patch Cord OS2 9/125 5m
T70-0388 SC/APC - SC/APC Singlemode Duplex Patch Cord OS2 9/125 10m
