CorePlus Elite Endurance General-Purpose Diamond Blade

The CorePlus Elite Endurance General-Purpose Diamond Blade features an Elite Endurance diamond metal matrix that extends the lifetime of the blade way beyond expectation.

A precision-engineered, hardened, high-grade 65Mn manganese steel tensioned core ensures the blade runs true. Double laser welding technology reduces the risk of damaged segments, combined with the maximum concentration of ultra-grade diamond that has been meshed within the bond. It also features a state-of-the-art, metallurgically engineered, high-performance and long-life bond formulation that ensures maximum durability and lifetime.

Manufactured to EN 13236 quality standard. oSa® certified to the highest level of quality and tested safety.

For cutting the following materials:

Blocks - Breeze
Clay - Paviours
Clay - Pipes
Clay - Roof Tiles
Concrete - Hard Aggregates
Concrete - Paving Slabs
Concrete - Pipes
Concrete - Kerbs
Concrete - Tiles
Concrete - Cured
Concrete - Limestone
Concrete Lintels
Concrete - Lintels Reinforced
Bricks
Bricks - Engineering
Bricks - Hard Facing
Bricks - Medium Facing
Paviours - Hard
Paviours - Medium Block
Sandstone - Medium
Sandstone - Hard
Slate
Slate - Hard
Roofing Tiles
Quarry Tiles

Available in 115, 125, 230, 300 and 300mm.

Mills Part Numbers

P09-3853 Diameter 115mm (Bore: 22.23mm - Segment Height: 12mm - Segment Width: 2.3mm)

P09-0614 Diameter: 125mm (Bore: 22.23mm - Segment Height: 12mm - Segment Width: 2.3mm)

P09-0618 Diameter: 230mm (Bore: 22.23mm - Segment Height: 12mm - Segment Width: 2.6mm)

P09-0626 Diameter: 300mm (Bore: 20mm - Segment Height: 12mm - Segment Width: 2.8mm)

P09-0627 Diameter: 350mm (Bore: 25.4mm - Segment Height: 12mm - Segment Width: 3.0mm)
