Cable Bearer - Wall Type

Galvanised steel wall brackets for mounting cable bearers for supporting cables in manholes and joint boxes.

Available in type 1, 2, 3, 5, 8, 10, 12 - The type numbers indicate the number of brackets which the bearers will carry.

BT Openreach references:

Cable Bearer Wall Type 1 - 178mm - Ref: 070281
Cable Bearer Wall Type 2 - 278mm - Ref: 070282
Cable Bearer Wall Type 3 - 508mm - Ref: 070283
Cable Bearer Wall Type 5 - 813mm -  Ref: 070284
Cable Bearer Wall Type 8 - 1270mm - Ref: 070285
Cable Bearer Wall Type 10 - 1574mm - Ref: 070286
Cable Bearer Wall Type 12 - 1880mm - Ref: 070287

Mills Part Numbers

S83-3203 Cable Bearer Wall Type 1 - 178mm
S83-1058 Cable Bearer Wall Type 2 - 278mm
S83-3204 Cable Bearer Wall Type 3 - 508mm
S83-3205 Cable Bearer Wall Type 5 - 813mm
S83-3206 Cable Bearer Wall Type 8 - 1270mm
S83-3207 Cable Bearer Wall Type 10 - 1574mm
S83-3208 Cable Bearer Wall Type 12 - 1880mm
