HellermannTyton MDU Fanout Cable Internal G.657.A2 12F LC/APC

The Last Mile Fan Out Internal Cable is available in a pre-terminated LC/APC fanout design constructed using Grade B compliant connectors and a B2ca compliant fibre cable.

Designed to service four or twelve apartments within a multi-dwelling unit environment, the cable has been specifically chosen to facilitate rapid deployment for efficient customer connections.

The Last Mile Fan Out Internal Cable is designed to work with the HellermannTyton family of MDU solutions.

The cable diameter (2.3mm for 4 fibres or 2.8mm for 12 fibres) is optimised for trouble-free installation above or below corridor ceilings and a range of adhesives and IET 7671 approved fire-proof clips and installation tools are available.

For the fanout design, each pre-connectorised tail is protected with a 900µm furcation tube, colour coded to the internal fibre.

Each connector is situated 400mm from the cable’s manifold for easy installation into the MDU range of enclosures.

Available in 4 different lengths: 25m, 50m, 100m or 250m. The 250m length is supplied on a spool for convenient deployment along corridors.

Features & Benefits:

Colour coded fibres and transportation tubes
LC/APC connectors IEC 61753-1 Grade B compliant
Operation and installation temperatures -10°C to 60°C
Bend radius, 20xOD loaded (during installation) & 10xOD unloaded (permanent)
Cable contains a rip cord for easy mid-span access
Cable construction contains central easy-strip loose tube which isolates the fibres from the aramid yarns

Mills / HellermannTyton Part Numbers

LMFC-IA2-12LP40-025 MDU Fanout Cable Internal G.657.A2 12F LC/APC 400mm 25m

LMFC-IA2-12LP40-050 MDU Fanout Cable Internal G.657.A2 12F LC/APC 400mm 50m

LMFC-IA2-12LP40-100 MDU Fanout Cable Internal G.657.A2 12F LC/APC 400mm 100m

LMFC-IA2-12LP40-250 MDU Fanout Cable Internal G.657.A2 12F LC/APC 400mm 250m
