VeEX FX41xT PON-T Power Meter with Broadband OPM

Selective PON Optical Power Meter for G-PON and XGS-PON

10G Next-Gen and Legacy PON Optical Power Meter

Provides fast, simple, and precise measurement of G-PON and XGS-PON downstream signals. Miniature filters ensure each wavelength is measured accurately. The tester is well suited for installation, service verification, and troubleshooting of co-existent networks, including IEEE based E-PON and 10G-EPON deployments.

Downstream signal verification for 1G/10G PON networks
Simultaneous 1490/1577 nm signal level measurements
Pass/Fail indication per ODN Class or User thresholds
Alkaline or rechargeable NiMH batteries with Auto- off
Save up to 2000 measurements with date and timestamp
Save/display test results via NoApp™ QR code for mobile device transfer, post-processing, sharing, and upload
Cloud-based NoApp™ service (included) allows for data augmentation via mobile phone or tablet. Secured and always up to date. No installation or updates required.
Micro USB interface for 5V DC powering and battery charging
High contrast backlit, monochrome display - visible outdoors and indoor with varying light conditions
Splash and dust resistant keypad and chassis design
Rugged polycarbonate chassis for demanding field conditions
Fixed SC/APC connector interface with protective dust caps
Visual Fault Locator (VFL) option
Broadband Optical Power Meter (OPM) option

Please contact our sales department for further information.
