Uninsulated Tubular Ring Terminal M6 Stud Size - Pack of 25

High-quality heavy-duty tubular crimp ring terminal, also known as a ring connector or cable lug.

Used for connecting multi-stranded cables to a stud or a post on an electrical component such as a battery terminal.

This tubular ring terminal is made from thick-walled, heavy-duty, highly conductive copper and is tin plated.

Once correctly crimped onto a cable this ring terminal will provide a secure and reliable electrical connection.

Available in the following options:

Maximum Wire Size: 6mm²
Overall Length: 23mm

Maximum Wire Size: 10mm²
Overall Length: 30mm

Specifications
Insulation: Uninsulated
Inner Ring Diameter: 6.4mm
Stud Size: M6
Contact Plating: Tin
Contact Material: Copper

Mills Part Numbers

E14-2079 Uninsulated Tubular Ring Terminal, M6 Stud Size to 6mm² Wire Size Pk25

E14-2080 Uninsulated Tubular Ring Terminal, M6 Stud Size to 10mm² Wire Size Pk25
