Tube Distribution Closure

The Tube Distribution Closure (TDC) can be Direct Buried into a waiting trench (following DB fibreflow installation procedures on back-fill) or placed inside a manhole or handhole.

• Accepts Fibreflow™ tube bundles and subducts up to 40mm (1.6”) in diameter

• One piece grommet and seal arrangement

• Manifold option allows 6 x 1 DB to be dropped off from 1 port.

• Captivated screws in lid portion allowing inverted installation

• Can be re-entered

• Can be retro-fitted to existing tube bundles/subducts

• Straight through, H, Y and T configurations possible

• IP40 rated

• Lightweight - 1.2 Kg (2.6 lb)

Materials : Plastics hell.

All metallic parts - Stainless Steel

Dimensions: Length: 316mm (12.4”) Width: 220mm (8.7”) Height: 70mm (2.8”)

Colour: Black
