Tempo Tele-Mate Test Telephone - TM-700

The TEMPO Communications TM-700 telephone buttset helps technicians install, service, and maintain voice services with ease.

DSL compatible in both Monitor and Talk modes, the TM-700’s LCD screen makes reading polarity, voltage, current, and ringing frequencies easier than ever, and clearly shows speed dials and recent numbers for faster access.

The TM-700 features over-voltage and over-current detection for safer operation and also features an intercom mode, a built-in toner for pair tracing, and DTMF detection and measurement for enhanced productivity.

Use the built-in loudspeaker or with a headset (included) for easy hands-free operation.

The Tempo Communications TM-700 makes your job faster, safer, and easier.

Features

Designed for comfortable shoulder placement. Operate in either hand, clip onto the belt, or use hands free.
Allows alerting and talking over a “dead” pair of wires.
A built-in pair tracing toner is provided. The frequencies chosen are suitable for use with Tempo probes, as well as any other probe that works in the audio range.
Make many jobs hands-free.
Advanced silicone rubber keypad glows after exposure to light, aiding operation in low light conditions.
LCD for easy dialing, programming, caller ID, voltage, current, ringing, and DTMF measurements
Safe over voltage and over current protection
Intercom for “dead-pair” talking
SmartIntercom™ between Tele-Mate® Pros (including PE830); allows “ringing” the far end
Tone generator for pair identification
Luminescent (glow-in-the-dark) keypad
DSL line filter
Super Impedance Amplifier to monitor lines without disrupting traffic

Specifications

Application: Test Telephone (buttset) with High-impedance monitor, LCD, Smart Intercom, Calling Line ID, Pair tracing toner, DTMF decoding, Multiple last-number redial and ten speed-dial memories

DC Voltage: TNV-3 working, 500 V peak, 1500 V TRANSIENT
Dimensions: 9.25 (235 MM) Length X 2.5 (64 MM) Width X 3.25 (83 MM) Height
Leakage: > 10 M ohms
Loop Current: < 10 mA < I < 125 mA
Replacement Part: Replaces PE830, Spares CS-01,CS-02, CS-03, CS-04, CS-05, CS-06, CS-07, HS-001
Standard: TIA/EIA-470-B and ETSI
Storage Operating Temperature: -10 C to +70 C, <95% humiditystorage, 0 C to +50 C, <90 % humidity (no condensation) operating
Voltage Measurement:110 V dc max

Available in the following models

TM-700i Test Set with Small Croc Clips 52063087

TM-700UK Test Set with BT Plug 52063088

See datasheets for further details

Mills part numbers

C00-4435 Tempo Tele-Mate TM-700i Test Telephone with Croc Clips

C00-4111 Tempo Tele-Mate TM-700UK Test Telephone with BT Plug
