Tempo Optical Power Meter & Stabilised Light Source Kits

Tempo Communications optical power meter and LED / laser source kits available in a variety of configurations.

Comprising:

SM DUAL KIT - OPM510 & SLS520
SM DUAL KIT HP - OPM520 & SLS520
MM DUAL KIT - OPM510 & SLS525
SM T PON KIT - OPM510 & SLS530
SM T 1625 KIT - OPM510 & SLS535
SM T 1650 KIT - OPM510 & SLS536
SM T PON KIT HP - OPM520 & SLS530
SM T 1625 KIT HP - OPM520 & SLS535
SM T 1650 KIT HP - OPM520 & SLS536
SMMMKIT-T - OPM510 & SLS520, SLS525
SMMMKIT-M - OPM520 & SLS520, SLS525

Optical Power Meters

OPM510 - Measurement range -65 ~ +10(1) dBm, Linearity +/-0.5dB (+10 to -3dBm)+/-0.1dB (-3 to -50dBm)+/-0.5dB (-50 to -65dBm)

OPM520 - Measurement range -50 ~ +27 dBm, Linearity +/-0.5dB +27 to -3dBm+/-0.1dB -3 to -50dBm

Stabilised Light Sources

SLS520 - Wavelength 1310/1550

SLS525 - Wavelength 850/1300

SLS530 - Wavelength 1310/1490/1550

SLS535 - Wavelength 1310/1550/1625

SLS536 - Wavelength 1310/1550/1650

See datasheets for full specifications

Mills Part Numbers

C00-4129 Tempo MM DUAL KIT Multimode Kit Dual (OPM510 & SLS525)

C00-4128 Tempo SM DUAL KIT HP Singlemode Kit MSO Dual (OPM520 & SLS520)

C00-4127 Tempo SM DUAL KIT Singlemode Kit TELCO Dual (OPM510 & SLS520)

C00-4130 Tempo SM T PON KIT Singlemode Kit TELCO PON (OPM510 & SLS530)

C00-4133 Tempo SM T PON KIT HP Singlemode Kit MSO PON (OPM520 & SLS530)

C00-4131 Tempo SM T 1625 KIT Singlemode Kit TELCO Live 1625 (OPM510 & SLS535)

C00-4132 Tempo SM T 1650 KIT Singlemode Kit TELCO Live 1650 (OPM510 & SLS536)

C00-4134 Tempo SM T 1625 KIT HP Singlemode Kit MSO Live 1650 (OPM520 & SLS535)

C00-4135 Tempo SM T 1650 KIT HP Singlemode Kit MSO Live 1650 (OPM520 & SLS536)

C00-4137 Tempo SMMMKIT-M MSO Optical Power Meter & Stabilised Light Source Kit (OPM520, SLS520 & SLS525)

C00-4136 Tempo SMMMKIT-T TELCO Optical Power Meter & Stabilised Light Source Kit (OPM510, SLS520 & SLS525)
