Tempo DFE Drop Fibre Enclosure Kit

The Drop Fibre Enclosure Kit is used to facilitate repairs of fibre optic cables. Common fibre sizes of 8.1mm, 5.4mm and 5.1mm rectangular cables, and 3.0mm and 5.1mm round cables are accommodated with the supplied sealing gaskets.

Both fusion splices (total of 24) and two mechanical splices are securely positioned within the IP68-rated, GR771 compliant enclosure. The enclosure can be permanently buried or mounted onto the side of a building.

Two DFE enclosures are typically used to repair a drop fibre as there is typically not enough slack cable to reconnect the fibres.

The DFE provides a splice point location within the network build as well as a demarcation point at the premises.

Available in the following configurations:

DFE100: Two Port In-Line

DFE101: Two Port Stub

DFE104: Four Port

Features

• IP68 rated for buried applications and element protection

• Accommodates up to 14 fibres

• Individual gaskets for 8.1, 5.4 and 5.1 mm and 3.0mm, 5.1mm round cable

• Fast assembly with common tools

Specifications

IP Rating IP68*

Size 8.85 x 4.72 x 1.34” (225 x 120 x 34mm)

Weight 0.66lb (0.3kg)

Cable Sizes 8.1mm rectangular, 5.4mm & 5.1mm rectangular and 3.0mm and 5.1mm round

Fusion Splice Locations Twelve (60mm)

Mechanical Splice Locations Two

Color Black

Material ABS with Polycarbonate (UV resistant)

Operating Temperature -40 to +80C

Storage Temperature -40 to +80C

See datasheet for further details

Mills Part Numbers:

C00-4146 Tempo DFE100 Drop Fibre Enclosure Kit 2 Port Inline

C00-4637 Tempo DFE101 Drop Fibre Enclosure Kit 2 Port Stub

C00-4638 Tempo DFE104 Drop Fibre Enclosure Kit 4 Port
