Taper Drill

Versatile hole-cutting tool for rapid drilling and enlarging holes in thin materials up to 2mm thick.

Designed for industrial applications, the diameter of the hole increases as the taper drill is advanced into the material, providing infinitely variable sizes

For use in sheet steel, non-ferrous metals, plastics, formica and plywood

The conical shape of the tool enables any size of hole to be drilled between the bottom and the top of the taper.

When drilling metals always use a coolant.

Available in the following sizes:

3 - 14mm

4 - 30.5mm

6 - 20mm

16 - 30mm

Mills Part Numbers

N47-1237 Taper Drill 3 - 14mm

T18-0013 Taper Drill 4 - 30.5mm

N47-1238 Taper Drill 6 - 20mm

N47-1239 Taper Drill 16 - 30mm
