SC/APC-SC/APC OS2 LSZH 3mm Simplex Singlemode Patch Lead G657A2 White

Singlemode fibre optic patch cord used to connect longer distance networks, between buildings and campuses and in long-distance metropolitan and access telecoms and CATV networks.

Supplied with a white LSZH cable jacket in 3mm diameter cable as standard.

Bend Insensitive G657A2 singlemode fibre.

Application

Data Centres
LAN/Enterprise
Metropolitan and access networks
FTTH
CATV
Transmission, switch and test equipment

Features

LSZH - Low smoke zero halogen, white jacket
900μm tight buffer, 3mm simplex
G657A2 fibre conforms to or exceeds all relevant ISO/IEC, TIA/EIA and ITU standards

Available in 0.5m, 1m. 2m, 3m, 5m and 10m lengths.

Mills Part Numbers

T70-3830 0.5m SC/APC-SC/APC OS2 LSZH 3mm Simplex Singlemode Patch Lead G657A2 White

T70-3831 1m SC/APC-SC/APC OS2 LSZH 3mm Simplex Singlemode Patch Lead G657A2 White

T70-3832 2m SC/APC-SC/APC OS2 LSZH 3mm Simplex Singlemode Patch Lead G657A2 White

T70-3833 3m SC/APC-SC/APC OS2 LSZH 3mm Simplex Singlemode Patch Lead G657A2 White

T70-3834 5m SC/APC-SC/APC OS2 LSZH 3mm Simplex Singlemode Patch Lead G657A2 White

T70-3835 10m SC/APC-SC/APC OS2 LSZH 3mm Simplex Singlemode Patch Lead G657A2 White
