SC/APC-SC/APC Internal / External Dual Sheath G657A2 Simplex Singlemode Patch Lead

Singlemode fibre dual sheath patch lead for outdoor/indoor installations.

Supplied with a black outer sheath (4.5mm) and has a rip cord to strip back to a white sheath (3mm).  The connector type is SC/APC both ends. Supplied with test certificate.

Available in the following lengths: 5m, 10m, 15m, 25m, 30m, 40m and 50m

Features

Halogen free, fire resistant inner sheath

LSZH = Low smoke zero halogen

Singlemode OS2 with G657A2 fibre

4.5mm outer sheath / 3mm inner sheath

Excellent installation and temperature performance

SC/APC connectors on both ends

Mills Part Numbers

T70-3850 Int/Ext Dual Sheath G657A2 Simplex SM Patch Lead SC/APC-SC/APC 4.5mm/3mm Diameter - 5m
T70-3851 Int/Ext Dual Sheath G657A2 Simplex SM Patch Lead SC/APC-SC/APC 4.5mm/3mm Diameter - 10m
T70-3852 Int/Ext Dual Sheath G657A2 Simplex SM Patch Lead SC/APC-SC/APC 4.5mm/3mm Diameter - 15m
T70-3853 Int/Ext Dual Sheath G657A2 Simplex SM Patch Lead SC/APC-SC/APC 4.5mm/3mm Diameter - 20m
T70-3854 Int/Ext Dual Sheath G657A2 Simplex SM Patch Lead SC/APC-SC/APC 4.5mm/3mm Diameter - 25m
T70-3855 Int/Ext Dual Sheath G657A2 Simplex SM Patch Lead SC/APC-SC/APC 4.5mm/3mm Diameter - 30m
T70-3856 Int/Ext Dual Sheath G657A2 Simplex SM Patch Lead SC/APC-SC/APC 4.5mm/3mm Diameter - 40m
T70-3857 Int/Ext Dual Sheath G657A2 Simplex SM Patch Lead SC/APC-SC/APC 4.5mm/3mm Diameter - 50m
