SAGAB Volt Stick 230Y Voltage Tester 230V AC Yellow

A non-contact voltage pen for safely checking the presence of an AC voltage without making any disconnections in cables, wall sockets, fuses, circuit breakers, junction boxes, etc. Applying the tip of the Voltstick to the equipment area/ cable to be tested, will result in the tip glowing red when an AC voltage is detected.

• Yellow 230V tester
• Locate breaks in cables
• Detect blown fuses
• Distinguishes between live and neutral in single and three-phase supplies
• Identifies voltage-carrying cables in junction boxes etc.
• Checks the functionality of circuit breakers and switches
• Tip illuminates red to indicate a voltage
• Fully insulated and approved, for safe use
• Voltage range: 230Vac, 50-60Hz
• Sensitivity: indicator will illuminate at 4mm distance of a 2.5mm² conductor carrying 220V
• Altitude: 2000m
• Safety: CATIII, 1000V
• Operating temperature: -10 to +50°C
• Response time: instantaneous
• Power supply: 2x 1.5V AAA batteries (supplied)
• Weight: 40g (including batteries)
• Dimensions: 147x17mm Ø

Product Information

• Voltage Measuring Range AC: 1kV
• Meter Display Type: LED
• Operating Temperature Min: -29°C
• Operating Temperature Max: 230°C
• Product Range: Sageb - Voltstick
