Runpotec CW 800 E Capstan Cable Pulling Winch with Trolley

Ideally suited for horizontal pulling of one or more cables.

Where several persons are needed for higher pulling loads on many sites, one person is sufficient to pull in the cables with the CW 800 E capstan winch from RUNPOTEC with a choice of 4 m/min |max. 800 kg or 8 m/min |max. 400 kg.

The capstan winch can be fixed via the mounting holes or attached to solid objects with the enclosed strap. The trolley mounting rail also offers a very practical fastening option.

It can be attached to the trailer hitch of a vehicle through the special coupling opening.

It is also possible to mount the rail horizontally or vertically, and then simply hook in the CW 800 E capstan winch and fasten it using the two fixing bolts.

Features

One person can pull up to 800 kg with the CW 800 E capstan winch
Selectable traction force or traction speed 800 kg|400 kg
Small, compact, handy
Many mounting options
Safety rope guide
Overload protection

Specifications

Weight Capstan Winch 32 kg
Weight Winch + Trolley + Trap 41,20 kg
Capstan Pulling Force up to 800 kg at 4m per min
Capstan Pulling Force up to 400 kg at 8m per min
Motor Available in 110 and 240v
Motor Drive Power 0,75 KWh | 5,1 A
Motor Speed 1400 U/min
Dimension Winch 37 cm x 50 cm x 33 cm
Dimension Trolley 23,5 cm x 100 cm x 20,5 cm
Strap Length 3 m

Mills Part Numbers

S00-6934 Runpotec CW 800 E Capstan Cable Pulling Winch with Trolley 110v

S00-6933 Runpotec CW 800 E Capstan Cable Pulling Winch with Trolley 240v
