Ripley Cablematic CST Coring, Stripping & Chamfering Tool with 3/8ʺ Drill Adaptor

Combination tool quickly strips the sheath & cores the dielectric on cables in one precise operation.

Features

• Durable, all-metal construction with color-coded guide sleeves provide easy identification
• Heat-treated sheath cutting blade produces a smooth, beveled edge & can be replaced
• Strip stops available for strip lengths of 0.5″ to 2″ (12.7 to 50.8 mm)
• Standard models feature a “T” handle with a built-in 3/8″ drill adapter & ratchet models feature a ratchet “T” handle with a separate 3/8″ drill adapter for manual or drill operations

Available for the folowing cable sizes

565 kcmil / .565 - CommScope® P3, Times Fibre TX (Standard)

625 kcmil / .625 - CommScope® P3, Times Fibre T10, Alcatel / Benelux ACE/ACW (Ratchet)

750 kcmil / .750 - CommScope® P3, Times Fibre T10, Alcatel / Benelux ACE/ACW (Ratchet)

840 kcmil / .840 - CommScope® P3, Times Fibre TX (Standard)

875 kcmil / .875 - CommScope® P3, Times Fibre T10, Alcatel / Benelux ACE/ACW (Ratchet)

Please see datasheet for further details

Mills Part Numbers

C00-4199 565 kcmil / .565 - CST 565TX 31985
C00-4185 625 kcmil / .625 - CST 625-R 32050
C00-4187 750 kcmil / .750 - CST 750-R 32150
C00-4201 840 kcmil / .840 - CST 840TX 32180
C00-4189 875 kcmil / .875 - CST 875-R 32250
