Prysmian SJC Small Joint Closure 24 Splices

The SJC Closure is a splice closure that is used for track or branch applications.

It has 4 cable entry ports, a splice cassette for 24 splices and a cable management and storage area.

The closure is sealed to IP68 for water and dust tightness.

The closure is supplied with four knock-out ports and two entry glands.

Up to two additional entry glands can be ordered separately.

Features and Benefits

• A compact closure for track and branch applications.

• Closure has four knock out ports.

• Each port accommodates a cable gland for cables 5-9mm or 6-12mm.

• Closure is supplied with two glands. Additional glands are available separately.

• Contains a single splice tray for up to 24 splices. • Splice tray accommodates 2.2mm splice protectors.

• Cable management plate to secure cables and route fibres.

• Robust construction enabling direct buried applications.

• Can be used underground or can be mounted to a wall.

• Sealed to IP68 at 5m and UV resistant to ISO 4892.

The SJC is supplied with: 1 x Base, 1 x Cover, 1 x O Seal, 1 x Splice Tray, 1 x Cable Management Plate 02 x Cable Entry Kits

Mills / Prysmian Part Numbers

XJTSC02335 Prysmian SJC Small Joint Closure 24 Splices for Cable 5-9mm

XJTSC02470 Prysmian SJC Small Joint Closure 24 Splices For Cable 6-12mm
