Prysmian CTP Customer Termination Point - Black

The Customer Termination Point has been designed and developed to accommodate the easy connection of a customer.

The CTP can be used for fibre to the premise applications with an integral splicing area as well as positions for up to 2 SC Simplex or LC Duplex adapters.

The CTP is wall mountable with entry positions for input/output cables on the bottom with two additional through the wall hole.

The CTP has provision for excess storage of up to 10m of 3mm cables, as well as up to 25m* of blown fibre units up to 1.25mm and allows separation of an incoming and outgoing cable for ease of access.

Available in the following configurations:

Splice Only - External Drop
Splice Only - Through Wall
1x LCA Duplex - External Drop
1x LCA Duplex - Through Wall
1x SCA Simplex - External Drop
1x SCA Simplex -Through Wall

Features

• Compact design.
• Stores up to 10m of 3mm cable, 25m* of blown fibre.
• Supports blown fibre/fixed cable access via UG , external or internal duct.
• Single person installation.
• IP55 rated.
• Moulded and assembled in the UK.
• Supplied in black as standard but also available in brown on request.

Technical data

 Max capacity (splices) 1
• Max number of drop cables: 4
• Diameter of cables: Input max 5mm
• Required space envelope (mm): (h) 185 x (w) 115.5 x (d) 42
• Operating temperature: -20oC to + 60oC (5 to 95% RH)
• Material: ABS, Foam (entry seals)
• Colour: Brown/Black
• Testing:
Ingress protection: IP55
Dry heat: IEC 60068-2-2 Test Bb
Change of temperature: IEC 60068-2-14
Damp heat: IEC 60068-2-78
Vibration: IEC 60068-2-6
Shock: IEC 60068-2-27
Impact: 0.25kg / 1m
Cable retention: 25N / 10min

Mills / Prysmian Part Numbers

XCPSC04640 Prysmian Customer Termination Point (CTP) - 1x LCA Duplex, 2x Cable Ties, 3x Foam Seals, Wall Mounting Kit - Black
XCPSC04638 Prysmian Customer Termination Point (CTP) - 1x LCA Duplex Through Wall - Black
XCPSC04632 Prysmian Customer Termination Point (CTP) - 1x SCA Simplex External Drop In - Black
XCPSC04630 Prysmian Customer Termination Point (CTP) - 1x SCA Simplex Through Wall - Black
XCPSC04648 Prysmian Customer Termination Point (CTP) - Splice Only External Drop - Black
XCPSC04646 Prysmian Customer Termination Point (CTP) - Splice Only Through Wall - Black
