PCLX 40E + 82v Battery Powered Plate Compactor C/W 8ah Battery & Charger (D)

FEATURES & BENEFITS
●    Engineered to be robust and durable for rental and heavy contractor usage.

●    Lightweight yet durable for easy transport. Fits in a standard car boot when the handle is folded.

●    Low Hand-Arm Vibration design for longer safe usage times.

●    High performance 13kN vibration unit gives excellent compaction force and travel speeds.

●    Environmentally friendly, emission free for use indoors & in poorly ventilated areas such as basements and tunnels.

●    Can be operated in environmentally sensitive areas, such as green spaces, nature reserves, national parks, rural railway cuttings and emission controlled urban areas, without any exhaust emissions.

●    No routine power unit maintenance eliminates servicing or costly downtime due to repairs.

●    Avoid problems with modern fuels. No blocked carburettors.

●    Cordless design gives added operational flexibility.

●    Quick release / connect 82v battery with digital power level display.

●    82v batteries are interchangeable with the other products in the Altrad Belle E+ 82v range, for added convenience and flexibility.

●    Baseplate designed for optimised speed and manoeuvrability.

●    Fitted with manual handling points.

●      Easy to operate and control, the baseplate does not dig in when dragged backwards or turned.

●     Optional paving pad for block paving applications available.

 TECHNICAL SPECIFICATIONS

Model   PCLX 40E+

Motor Power (Hp / kW) 2.0 / 1.5
Motor Type Brushless
Width(mm) 400
Operating Height (mm) 910
Operating Length (mm) 1060
Storage Height (mm) 500
Storage Length (mm) 780
*Weight (Kg) 62
Static Pressure (kg/m²) 337
Centrifugal Force (kN) 13
Frequency (Hz) 101
Max. Gradient () 20
Max. Travel Speed (m/min) 20
Vibration level (m/sec²) <2.5
Sound Power Level *weight without battery
