Milwaukee MX Fuel 150mm Core Drill

Core with confidence by delivering AC performance with a maximum core diameter capacity of 152 mm wet & dry.

2 speed gearing for a wide range of applications, with laser etched speed and capacity markings into the metal body.

Speed 1: up to 75 mm diameter wet & dry coring at 1600 rpm
Speed 2: 76 to 152 mm diameter wet & dry coring 800 rpm

Patented AUTOSTOP™ clutch provides best in class protection, preventing over rotating when losing control or in
case of a stuck core,

On-board level sensor guides the user to achieve a straight and accurate finish whilst horizontal drilling.

On-board pressure gauge allows user to optimise drilling speed in order to get the best lifetime of machine and
accessory.

On-board battery gauge allows the user to monitor battery capacity during entire drilling process.

Integrated water line for wet coring that is compatible with the M18™ SWITCH TANK™ interchangeable sprayer and water supply system.

1 ¼″UNC + ½″G core fitting to fit most common cores, with friction plate design allowing for easy core changes.

Separately available core drill stand MXF DR255TV with 60 mm collar - 60 mm mount on the core drill fits most universal core stands.

ONE-KEY™ tool tracking & security offers a free of charge cloud-based tracking network and inventory management platform for your tools. ONE-KEY™ also features a remote locking functionality.

No load speed (rpm) 0 - 800/ 0 - 1600
Drilling capacity in concrete
1st| 2nd gear [mm] 76 - 152/ 25 - 76
Tool reception 1 ¼″ UNC + ½″ G
Weight with battery pack
(EPTA) (kg) 12.4 (MXF CP203)
Standard equipment Trigger lock-on, side handle

Available in the following configurations:

Bare unit only with kitbox ( Milwaukee no. MXF DCD150-0C )

Suppled with 2 x MXF CP203 Battery packs, MXF C Charger, Kitbox ( Milwaukee no. MXF DCD150-302C )

Mills Part Numbers

P09-0550 Milwaukee MX Fuel MXF DCD150-0C 150mm Diamond Core Drill - Bare Unit

P09-1027 Milwaukee MX Fuel MXF DCD150-302C 150mm Core Drill Kit with 2x 3Ah Batteries and Charger
