Mills Connector Fused Swivel

Mills fused swivel specially designed for the safe installation of fibre optic cables and featuring a patented shear bolt design which gives breaking accuracy of +/- 5% ensuring the cable is not subjected to excessive pulling forces.

The precision machined body is manufactured from hardened steel and featured two precision thrust races to reduce cable twist.

These connector fused swivels are available individually in a choice of 16 and 22mm diameters with 4 popular breaking strains, covering 1kN. 1.5kN, 2kN and 3kN. The different breaking strains of the swivel are easily identified by colour coded washers as follows:

Yellow 1kN.

Green 1.5kN

Blue 2kN

Red 3kN

These connector swivels are also available in sets with a swivel body, colour identification washers and 2 of each shear pins covering 1kN. 1.5kN, 2kN and 3kN breaking strains.

Mills Part Numbers

S83-1840 Mills 16mm Fused Swivel Yellow 1kN
S83-1849 Mills 16mm Fused Swivel Green 1.5kN
S83-1850 Mills 16mm Fused Swivel Blue 2kN
S83-1851 Mills 16mm Fused Swivel Red 3kN
S83-1846 Mills 22mm Fused Swivel Yellow 1kN
S83-1855 Mills 22mm Fused Swivel Green 1.5kN
S83-1858 Mills 22mm Fused Swivel Blue 2kN
S83-1859 Mills 22mm Fused Swivel Red 3kN
