Mills Anti-Torsion Swivel Joint

Anti-torsion swivel joints suitable for joining both steel and synthetic pilot and pulling ropes, with pulling socks (Grips Cable). Made from chrome plated high tensile steel.

Available in 12, 18, 32, 45 and 60mm diameters, with breaking strains from 850 to 36,000kg.

12mm diameter

Breaking strain: 850kg. The swivel will accept wires and draw ropes up to 5mm diameter.
Dimensions: 12mm x 70mm.

18mm diameter

Breaking strain: 1200kg. The swivel will accept wires and draw ropes up to 9mm diameter.
Dimensions: 60mm Length x 18mm Diameter.

32mm diameter

Breaking strain: 8,000kg. The swivel will accept wires and draw ropes up to 15mm diameter.
Dimensions: 32mm x 120mm.

45mm diameter

Breaking strain: 18,000kg. The swivel will accept wires and draw ropes up to 19mm diameter.
Dimensions: 45mm x 170mm.

60mm diameter

Breaking strain: 36,000kg. The swivel will accept wires and draw ropes up to 24mm diameter.
Dimensions: 60mm x 220mm.

Mills Part Numbers

S03-6166 Mills Anti-Torsion Swivel Joint 12mm
S03-6617 Mills Anti-Torsion Swivel Joint 18mm
S03-4750 Mills Anti-Torsion Swivel Joint 32mm
S03-4751 Mills Anti-Torsion Swivel Joint 45mm
S03-4752 Mills Anti-Torsion Swivel Joint 60mm
