Megger DET2/3 High Resolution Earth Tester
The Megger ® DET2/3 automatic earth (ground) test instrument is robust, compact and designed to measure earth Electrode Resistance and Soil Resistivity. It provides a full range of test methods and excels
at the four terminal method of measurement, which eliminates the resistance of the current circuit from the measurement.
The DET2/3 is a reliable instrument for use on large or more complex earth systems, which include communications earth systems and difficult test environments.
It can be used to test in accordance with BS 7430 (earthing / grounding), BS-EN-62305 (Lightning Protection),
IEEE Standard 81 and Railway Applications.
Soil Resistivity measurements are used to establish the optimum electrode design and site, as well as archaeological and geological investigations.
Features
High resolution of 1 mΩ, ideal for large earth (ground) systems
Versatile test modes
High accuracy for earth (ground) electrode grid and soil resistivity tests
Rechargeable battery power that can last all day with a fast re-charge (up to 10 hours)
Robust instrument with IP65 protection
Automatic test frequency selection, with filters and high current features
Diagnostic trace display
Data storage
Large colour display that shows numeric and graphical results
Please see datasheet for further details
The Megger ® DET2/3 automatic earth (ground) test instrument is robust, compact and designed to measure earth Electrode Resistance and Soil Resistivity. It provides a full range of test methods and excels
at the four terminal method of measurement, which eliminates the resistance of the current circuit from the measurement.
The DET2/3 is a reliable instrument for use on large or more complex earth systems, which include communications earth systems and difficult test environments.
It can be used to test in accordance with BS 7430 (earthing / grounding), BS-EN-62305 (Lightning Protection),
IEEE Standard 81 and Railway Applications.
Soil Resistivity measurements are used to establish the optimum electrode design and site, as well as archaeological and geological investigations.
Features
High resolution of 1 mΩ, ideal for large earth (ground) systems
Versatile test modes
High accuracy for earth (ground) electrode grid and soil resistivity tests
Rechargeable battery power that can last all day with a fast re-charge (up to 10 hours)
Robust instrument with IP65 protection
Automatic test frequency selection, with filters and high current features
Diagnostic trace display
Data storage
Large colour display that shows numeric and graphical results
Please see datasheet for further details
