LastMile MDVN82KH Portable Compressor

Electro-galvanised bodywork and chassis with advanced painting procedure to grant an excellent preservation through time
Compact dimensions for easy handling and optimum dimensions / delivered power ratio
Stage IIIB-Tier 4 Final compliant, without DPF filtration system (less maintenance costs)
Filters “spin-on” type for quick maintenance
Full accessibility for easy and rapid maintenance and service
European homologation for road circulation with brakes.

Features

KOHLER Stage III B - Tier 4 Final engine. Without DPF filtration system (less maintenance costs)

Exclusive pneumatic control system, developed by ROTAIR, to adjust automatically engine revs, depending on the air to be delivered. This system is highly reliable and ensures fuel consumption saving.

Start/stop “INTELLIGENTSYSTEM”, exclusive from ROTAIR, to prevent the risk of incorrect procedures during specific functioning.

Air/oil separator filter, highly oversized, can guarantee an excellent air/oil separation.

The air and oil filters of the compressor and the air and oil filters of the engine are independent.

Two stages oversized air filter for compressor part, to guarantee good filtering of the air intake by airend.

Two-stage air filter for engine part.

Combined radiator allowing both compressor oil cooling and engine liquid cooling.

Designed for overblow

Options and Accessories

Drawbar with/without brakes
Caravan-type ball connection
Skid version
Clog indicator for engine air filter
Fuel indicator
Sandblasting kit (cooler for compressed air cooling and dew separator)
Line oiler for pneumatic tools
Warming for compressed air
Exclusive Rotair “Fuel Saving System” (saving up to 20% of fuel)

Technical Data

Operating pressure: 7 bar 102 psi : 10 bar 145 psi : 14 bar 203 psi

Free air delivery: 8000 l/min 282 cfm : 6400 l/min 226 cfm : 5000 l/min 177cfm

Minimum working pressure: 5,5 bar - 80 psi
Drive system engine-airend: Direct Drive
Compressor cooling system: Air / Oil
Oil cooling capacity: 16 lt - 3.52 UK gal
Air outlet temperature: 40°C - 105°F + Ambient temperature
Outlet valves: 2 x 3/4"+ 1 x 1"
Noise level EECno 2000/14 : < 98 LWA
Battery capacity : 12V cc - 950A-132Ah (EN)
Fuel tank capacity : 92 lt - 20.24 UK gal
Consumes : 9,3 lt/h - 2.05 UK gal/h (9,9 working hours)

Diesel Engine / Ennvironmental Conditions

Engine make: KOHLER
Engine type: KDI2504-TCR
Engine system: 4 strokes - Inline - Direct Injection
Emissions: Stage III B / Tier 4 Final
Filtration: DOC
Displacement: 2482 cc
N. cylinders: 4
Aspiration: Turbo Intercooler
Max engine power @2600 rpm: 55,4 kW - 73.6 HP
Max engine speed: 2100 RPM
Min engine speed: 1700 RPM
Cooling system: Water
Cooling system capacity: 17 lt - 3.74 UK gal
Lubrication system: Oil
Lubrication system capacity: 10 lt - 2.2 UK gal
Max ambient temperature: 50°C - 122°F
Max altitude: 1800 m a.s.l.
Min working temperature: -10°C / 14°F

Weight without brakes: 1386 kg

Weight with brakes: 1540 kg
