Internal Corridor Box - 3A Splice Bridges Included - No Adaptor

The HellermannTyton Internal Corridor Box (ICB) has been specifically designed to work in conjunction with the HellermannTyton 2.3mm and 2.8mm corridor cables. Up to 2m of cable can be stored in the box (or 4m if the cable jacket and aramid yarn are removed), allowing installer friendly fibre preparation at a nominal working height of 1m.
The box incorporates positive fibre management which ensures the fibres adhere to the minimum bend radius. A fire-resistant metal clip is fitted inside to comply with the current IET Wiring Regulations.
Fibre cable retaining features are incorporated into the design to ensure the cable remains secure once installed. Two rear-entry holes allow the trouble-free installation of the apartment reel cable through the wall behind the box.
The ICB is designed for horizontal or vertical installation with 4 entry/exit ports (2 at the top and 2 at the bottom of the base). This allows the corridor cable to pass through (inline) from the top or from the bottom or to enter and exit via one of the ports.

Features & Benefits:

Small, low-profile design from a UL-94 V0 material
Easy installation to corridor walls, either above or below the ceiling level
Designed to allow one or two 2.3 or 2.8mm corridor cables
to be installed
Provision for up to twelve splices to allow two cable section replacements in case of installation damage
Optional ability to install standard PLC splitters to allow for
multi-drop applications
Simple to use knockouts on each corner for diverting
cables to desirable positions
Clipped on/Screwed on cover. 3a splice bridge included.
