Hydraulic Cable Drum Lifting Jacks

Lightweight hydraulic drum jacks which are almost indispensable for use in the cable yard. Versatile and easily adjustable within seconds to accommodate vast ranges of drums. Excellent all-round stability. Fitted with wheels to be easily moved by one person. Complete with spindle bar & locking collars.

Available in 3, 6 and 10 Tonne Capacity SWL Per Pair

3 Tonne Capacity SWL Per Pair

Minimum Drum Diameter 800mm

Maximum Drum Diameter 2500mm

Base Area 830 x 700mm

Weight: 125kg/Set

6 Tonne Capacity SWL Per Pair

Minimum Drum Dia 880mm

Maximum Drum Dia 3000mm

Base Area 900x765mm

Weight: 176kg / Set

10 Tonne Capacity SWL Per Pair

Minimum Drum Dia 1080mm

Maximum Drum Dia 3500mm

Base Area 1060x985mm

Weight: 235kg / Set

Please note these maybe subject to an additional delivery charge - please enquire when ordering.

Mills Part Numbers

C00-3531 3 Tonne Hydraulic Cable Drum Lifting Jacks

C00-3532 6 Tonne Hydraulic Cable Drum Lifting Jacks

S00-6764 10 Tonne Hydraulic Cable Drum Lifting Jacks
