HellermannTyton MDU S1 XS IP54 Enclosure

The MDU S1 XS is V0 rated with an IP54 sealing performance. With up to 6 entry/exit ports at the bottom of the enclosure which are suitable for cables or ducts up to a maximum diameter of 8mm. A loop through facility allows for single fibre elements to be removed and spliced whilst the remaining fibres can be fed on to the next connection point.
Mechanical fixing is provided to secure all incoming/outgoing cable or blown fibre ducts and to provide strain relief where necessary. Internal positive fibre management and fibre retention clips maintain a minimum 30mm bend radius throughout.

Features & Benefits:

Capacity for up to 12 Customer Connections
Positive fibre management (30mm minimum bend radius)
Splitter accommodation
IP54 rating
UV Stable
Low Profile
Tamper-proof

Available with x 3 3A Splice Bridges or supplied with either 6 x SC/APC Simplex Adaptors or 6 x LC/APC Duplex Adaptors.

Mills / HellermannTyton Part Numbers

MDU-S1XS-T1XXX21X MDU S1 XS For 12 Customer Connections with 3 x 3A Splice Bridges

MDU-S1XS-T16TX21X MDU S1 XS For 12 Customer Connections with 6 x SC/APC Simplex Adaptors

MDU-S1XS-T16AX21X MDU S1 XS For 12 Customer Connections with 6 x LC/APC Duplex Adaptors
