HellermannTyton AFN Aerial Fibre Node

The AFN - Aerial Fibre Node is manufactured from UV stable polycarbonate with a completely detachable lid which can also be snapped back in to position using the snap back hinges allowing unrestricted access to all fibre management areas.

The enclosure has 3 separate management areas for inbound cable, fibre splice management and drop cable (customer connection) management.

The inbound cable management area has a dedicated cable entry port which supports both cable end and mid-span applications with loop storage capacity for up to 4m of 144 core fibre cable and the entry port is sealed with a cable entry kit to maintain the IP55 rating.

The fibre splice management area has capacity for a maximum of 48 (double stacked) 3A splices and maintains positive fibre management (30mm minimum bend radius) throughout.

The tray has a crossover facility which allows for alternative routing requirements and a fibre storage capacity of 1.5m for 250µm fibre.

The drop cable management area cover presents access to the network cables and splicing area and the adaptors are angled and spaced to allow for inspection prior to connection.

Twelve anchor guides are provided for securing the drop cables (maximum diameter 4.2mm) and an integral seal maintains the IP55 rating.

Features & Benefits:

4 Inbound/24 Outbound ports
Separation of inbound fibre from connectorised drop cables
Positive fibre management to maintain consistent 30mm minimum bend
PLC splitter accommodation (60mm x 7mm x 4mm)
IP55 and IK08 rating
Pole or building/facade mounted

Available as standard  in the following configurations:

8x LC/APC Simplex Adaptors with 1x 1:8 LC/APC BE Splitter

Maximum of 48 (double stacked) 3A splices

The drop cable management area presents 8 LC Simplex adaptors for connection to industry standard pre-terminated drop cables and a maximum of 1 x 1:8 PLC splitter (60mm x 7mm x 4mm) can be fitted on the inside of the management area.

16x LC/APC Simplex Adaptors with 2x 1:8 LC/APC BE Splitters

Maximum of 24 3A splices

The drop cable management area presents 16 LC Simplex adaptors for connection to industry standard pre-terminated drop cables and a maximum of 2 x 1:8 PLC splitter (60mm x 7mm x 4mm) can be fitted on the inside of the management area.

Mills / HellermannTyton Part Numbers

AFN-9999LCRS181/BK-1 HellermannTyton AFN with 1x 1:8 Bare End Splitter and 8x LC/APC SX Adaptors

AFN-9999LCRS281/BK HellermannTyton AFN with 2x 1:8 Bare End Splitter and 16x LC/APC SX Adaptors
