Grip Cable Fibre Optic

A specialist cable grip for fibre cables with a dual weave design made from galvanised wire rope.

Used for the installation of fibre optic cables for either overhead or underground applications.

Made of galvanised steel.

Specifications

2.5 - 5.6mm - Lattice Length: 265mm, Overall Length: 455mm, Break Load Approx: 431Kg
5.3 - 9.2mm - Lattice Length: 370mm, Overall Length: 560mm, Break Load Approx: 748Kg
8.1 -12.5mm - Lattice Length: 470mm, Overall Length: 690mm, Break Load Approx: 998Kg
10.7 - 15.8mm - Lattice Length: 515mm, Overall Length: 735mm, Break Load Approx: 1247Kg
13.5 - 19.1mm - Lattice Length: 595mm, Overall Length: 815mm, Break Load Approx: 1678Kg
16.3 - 22.4mm - Lattice Length: 645mm, Overall Length: 865mm, Break Load Approx: 1928Kg
19.1 - 25.5mm - Lattice Length: 720mm, Overall Length: 940mm, Break Load Approx: 1928Kg

Mills Part Numbers

S83-1790 Grip Cable Fibre Optic 2.5 - 5.6mm
S83-1791 Grip Cable Fibre Optic 5.3 - 9.2mm
S83-1796 Grip Cable Fibre Optic 8.1 -12.5mm
S83-1797 Grip Cable Fibre Optic 10.7 - 15.8mm
S83-1798 Grip Cable Fibre Optic 13.5 - 19.1mm
S83-1799 Grip Cable Fibre Optic 16.3 - 22.4mm
S83-1800 Grip Cable Fibre Optic 19.1 - 25.5mm
