Gas Block Straight Connector - Pack of 10

Connector that provides a tube to tube joint and seal as well as providing a low-pressure gas seal of the interstitial space between the tube and the fibre bundle.

Gas block connectors prevent gas from leaking past either the tube or the installed fibre-unit.

Gas block connectors are suitable sized to match the tube diameters.

When the fittings are pushed onto a clean-cut (!) tube end they make a seal with the internal O-Rings.

If the tube is pulled away from the connector, internal teeth and a tapered body cause the tube to be gripped tighter.

Removal of the tube is achievable by pressing the collet inwards.

Supplied in a pack of 10.

Available in the following sizes:

5mm for 0.9mm - 1.6mm Cable
7mm for 1.0mm - 1.6mm Cable
7mm for 1.8mm - 2.4mm Cable
8mm for 1.0mm - 1.6mm Cable
10mm for 5.5mm - 6.6mm Cable
10mm for 6.6mm - 7.2mm Cable
12mm for 5.5mm - 6.6mm Cable
12mm for 6.6mm - 7.2mm Cable
12mm for 7.2mm - 8.2mm Cable
14mm for 6.5mm - 7.2mm Cable
14mm for 8.0mm - 10.0mm Cable

Mills Part Numbers

Q69-6773 5mm Gas Block Straight Connector 0.9mm to 1.6mm Pk10
Q69-6770 7mm Gas Block Straight Connector 1mm to 1.6mm Pk10
Q69-6771 7mm Gas Block Straight Connector 1.8mm to 2.4mm Pk10
Q69-6799 8mm Gas Block Straight Connector 1mm to 1.6mm Pk10
Q69-6774 10mm Gas Block Straight Connector 5.5mm to 6.6mm Pk10
Q69-6775 10mm Gas Block Straight Connector 6.6mm to 7.2mm Pk10
Q69-6776 12mm Gas Block Straight Connector 5.5mm to 6.6mm Pk10
Q69-6777 12mm Gas Block Straight Connector 6.6mm to 7.2mm Pk10
Q69-6778 12mm Gas Block Straight Connector 7.2mm to 8.2mm Pk10
Q69-6779 14mm Gas Block Straight Connector 6.5mm to 7.2mm Pk10
Q69-6780 14mm Gas Block Straight Connector 8mm to 10mm Pk10
