Emtelle G652D SM Mini Cable

Minicables are for blowing into the duct network. They can be installed in single microducts or tube bundles. The cables are light-weight and smaller in diameter than traditional cables, enabling a higher fibre count within a small microduct.
Cable consists of stranded core with central strength element (FRP) and gel filled loose tubes with optical fibres. Stranded core is fixed by water swellable yarns. Outer sheath is made of polyamide PA12. Colour of outer sheath is black.
Available colour codes are ANSI / TIA 598, DIN VDE 0888, S12, FIN2012.

Supplied in reels, request for longer lengths.

• Ease of handling and durability
• Compatible with industry-standard blowing equipment
• Low friction coating for best blowing results
• Supplied on reels to ease fibre handling
• Fibre beads supplied in pan to enable blowing through connectors
• Supplied in lengths of 2KM and 4KM (lengths up to 12KM available on request)
• Gel filled loose tubes and water blocking yarns
• Light-weight and dielectric design

Mills Part Numbers

75427/2KM 144F Mini Cable G652D 200u Black (5.4mm) 2000m

75427/4KM 144F Mini Cable G652D 200u Black (5.4mm) 4000m
