Fusion Contract Series Wall Cabinet - Extra Deep

Designed for large contract applications, the Fusion Contract series cabinets offer stylish design and top quality at highly competitive prices.

The range comprises standard wall cabinets, swing back cabinets and free standing cabinets, all complying with ANSI/EIA RS-310-D, IEC60297-2 and DIN41494 Part 7.

These 600mm wide x 600mm deep wall cabinets are manufactured from 1.2mm steel and feature removable side panels for maximum access and a reversible, reinforced glass door.

1.2mm welded steel construction
Reversible reinforced lockable glass door
Removable quick-release ‘lift-out’ lockable side panels
Fully adjustable front and rear profiles
Gland plate with knock-outs top and bottom
One 100 x 50mm and one 50 x 50mm trunking knock-out
Two 25mm conduit knock-outs
One 370 x 55mm cable access strip plate
Wall mounting plate
3 pairs of keys

Available in sizes 6U, 9U,12U, 15U and 18U

Image shows 9U wall box.

Height

6U - 370mm
9U - 500mm
12U - 635mm
15U - 770mm
18U - 910mm

Weight

6U - 20kg
9U - 24kg
12U - 27kg
15U - 31kg
18U - 35kg

All cabinets are non-returnable & non-refundable. If there are any damages on the outer packaging please sign for as 'damaged' and upon receipt, please contact us immediately.

*18U Cabinet - Due to the size of this cabinet, it will be dispatched on a pallet to ensure safe passage and will be subject to an additional delivery charge.

Mills Part Numbers

T98-4241 Fusion Contract Series Wall Cabinet Extra Deep 6U
T98-4242 Fusion Contract Series Wall Cabinet Extra Deep 9U
T98-4243 Fusion Contract Series Wall Cabinet Extra Deep 12U
T98-4244 Fusion Contract Series Wall Cabinet Extra Deep 15U
T98-4570 Fusion Contract Series Wall Cabinet Extra Deep 18U
