Fibre Optic Patch Cord Multimode Duplex - OM1

OM1 62.5u multimode patch cords are used in legacy 1000Base networks common in LAN applications.

All assemblies are fully tested prior to delivery and supplied with test results.

OM1 multimode patch cords are supplied with 3mm cable (for additional ruggedising) LSZH cable jacket as standard.

Application

LAN/Enterpise and legacy networks
For use in 1GB/s networks over >275M indicative link length at 850nm (SX) wavelength

Features

LSZH - Low smoke zero halogen, grey jacket
900µm / 600µm tight buffer, 3mm duplex cable
OM1 fibre conforms to or exceeds all relevant ISO/IEC, TIA/EIA and ITU standards
All patch cords come with a UPC polished connector end face as standard

Fibre Specification

Attenuation (db/km) ≤ 2.7 @ 850nm / ≤ 0.6 @ 1300nm

Overfilled Modal Bandwidth (MHz x km ) ≥ 200 @ 850nm / ≥ 500 @ 1300nm

Cable Specification

Cable Material LSZH

Strength Member Aramid

Crush (N/100mm) 1000

Tensile (N) 120

Operating Temperature (°C) -20 to 60

Connector Specification

IL Max/Master (db) (Acceptance) ≤ 0.25

Av./Random (db) ≤ 0.20

Colour: Grey

Mills Part Numbers

T70-2334 LC-LC Multimode Duplex Fibre Patch Cord OM1 62.5/125um 1m
T70-2335 LC-LC Multimode Duplex Fibre Patch Cord OM1 62.5/125um 2m
T70-2336 LC-LC Multimode Duplex Fibre Patch Cord OM1 62.5/125um 3m
T70-0097 LC-LC Multimode Duplex Fibre Patch Cord OM1 62.5/125um 5m
T70-0098 LC-LC Multimode Duplex Fibre Patch Cord OM1 62.5/125um 10m

T70-2265 LC-SC Multimode Duplex Fibre Patch Cord OM1 62.5/125um 1m
T70-2266 LC-SC Multimode Duplex Fibre Patch Cord OM1 62.5/125um 2m
T70-2267 LC-SC Multimode Duplex Fibre Patch Cord OM1 62.5/125um 3m
T70-0106 LC-SC Multimode Duplex Fibre Patch Cord OM1 62.5/125um 5m
T70-0107 LC-SC Multimode Duplex Fibre Patch Cord OM1 62.5/125um 10m

T70-2340 LC-ST Multimode Duplex Fibre Patch Cord OM1 62.5/125um 1m
T70-2341 LC-ST Multimode Duplex Fibre Patch Cord OM1 62.5/125um 2m
T70-2261 LC-ST Multimode Duplex Fibre Patch Cord OM1 62.5/125um 3m
T70-0088 LC-ST Multimode Duplex Fibre Patch Cord OM1 62.5/125um 5m
T70-0089 LC-ST Multimode Duplex Fibre Patch Cord OM1 62.5/125um 10m

T70-2235 SC-SC Multimode Duplex Fibre Patch Cord OM1 62.5/125um 1m
T70-2236 SC-SC Multimode Duplex Fibre Patch Cord OM1 62.5/125um 2m
T70-2237 SC-SC Multimode Duplex Fibre Patch Cord OM1 62.5/125um 3m
T70-2238 SC-SC Multimode Duplex Fibre Patch Cord OM1 62.5/125um 5m
T70-2239 SC-SC Multimode Duplex Fibre Patch Cord OM1 62.5/125um 10m

T70-2245 ST-SC Multimode Duplex Fibre Patch Cord OM1 62.5/125um 1m
T70-2246 ST-SC Multimode Duplex Fibre Patch Cord OM1 62.5/125um 2m
T70-2247 ST-SC Multimode Duplex Fibre Patch Cord OM1 62.5/125um 3m
T70-2248 ST-SC Multimode Duplex Fibre Patch Cord OM1 62.5/125um 5m
T70-2249 ST-SC Multimode Duplex Fibre Patch Cord OM1 62.5/125um 10m

T70-2225 ST-ST Multimode Duplex Fibre Patch Cord OM1 62.5/125um 1m
T70-2226 ST-ST Multimode Duplex Fibre Patch Cord OM1 62.5/125um 2m
T70-2227 ST-ST Multimode Duplex Fibre Patch Cord OM1 62.5/125um 3m
T70-2228 ST-ST Multimode Duplex Fibre Patch Cord OM1 62.5/125um 5m
T70-2229 ST-ST Multimode Duplex Fibre Patch Cord OM1 62.5/125um 10m
