Drill Bit Metal Twist - Straight Shank

HSS jobber drills : toughness and precision combined with excellent cutting efficiency for drilling alloyed carbon and plain steel.

Break resistant with high elasticity and durability.

Special point shape for speed.

DIN338.

Available in diameters of 1.0 to 13mm

Lengths

1.0mm - Length 34mm (Working length 12mm)
1.5mm - Length 40mm (Working length 18mm)
2.0mm - Length 49mm (Working length 24mm)
2.5mm - Length 57mm (Working length 30mm)
3.0mm - Length 61mm (Working length 33mm)
3.5mm - Length 70mm (Working length 39mm)
4.0mm - Length 75mm (Working length 43mm)
4.5mm - Length 80mm (Working length 47mm)
5.0mm - Length 86mm (Working length 52mm)
5.5mm - Length 93mm (Working length 57mm)
6.0mm - Length 93mm (Working length 57mm)
6.5mm - Length 101mm (Working length 63mm)
7.0mm - Length 109mm (Working length 69mm)
7.5mm - Length 109mm (Working length 69mm)
8.0mm - Length 117mm (Working length 75mm)
8.5mm - Length 117mm (Working length 75mm)
9.0mm - Length 125mm (Working length 81mm)
9.5mm - Length 125mm (Working length 81mm)
10.0mm - Length 133mm (Working length 87mm)
10.5mm - Length 133mm (Working length 87mm)
11.0mm - Length 142mm (Working length 94mm)
11.5mm - Length 142mm (Working length 94mm)
12.0mm - Length 151mm (Working length 101mm)
12.5mm - Length 151mm (Working length 101mm)
13.0mm - Length 151mm (Working length 101mm)

BT Openreach references:

2.0mm - Ref 127018
3.0mm - Ref 127019
4.0mm - Ref 127020
5.0mm - Ref 127021
6.0mm - Ref 127022
7.0mm - Ref 127023
8.0mm - Ref 127024
9.0mm - Ref 127025
10.0mm - Ref 127026
11.0mm - Ref 127027
12.0mm - Ref 127028
13.0mm - Ref 127029

Mills Part Numbers

N63-3000 1mm Twist Drill
N63-3001 1.5mm Twist Drill
N63-3002 2mm Twist Drill
N63-3003 2.5mm Twist Drill
N63-3004 3mm Twist Drill
N63-3005 3.5mm Twist Drill
N63-3006 4mm Twist Drill
N63-3007 4.5mm Twist Drill
N63-3008 5mm Twist Drill
N63-1009 5.5mm Twist Drill
N63-1010 6mm Twist Drill
N63-1011 6.5mm Twist Drill
N63-1012 7mm Twist Drill
N63-1013 7.5mm Twist Drill
N63-1014 8mm Twist Drill
N63-1015 8.5mm Twist Drill
N63-1016 9mm Twist Drill
N63-1017 9.5mm Twist Drill
N63-1018 10mm Twist Drill
N63-1019 10.5mm Twist Drill
N63-1020 11mm Twist Drill
N63-1021 11.5mm Twist Drill
N63-1022 12mm Twist Drill
N63-1023 12.5mm Twist Drill
N63-1024 13mm Twist Drill
