Drill Bit Masonry - Straight Shank

Tungsten carbide tip, long life masonry drill bit with milled flutes for percussion and rotary drilling in concrete, brick and natural stone. DIN ISO 5468.

Available from 5 - 20mm diameter, up to 400mm overall length.

Openreach references

5.0 x 85mm - Ref: 126702

5.5 x 85mm - Ref: 127264

7.0 x 100mm - Ref: 126701

8.0 x 120mm - Ref 126817

Mills Part Numbers / Working Lengths

N36-1171 Straight Shank Masonry Drill 5 x 85mm (No.8) (Working Length 39mm)
N36-1172 Straight Shank Masonry Drill 5.5 x 85mm (No.10) (Working Length 39mm)
N36-1173 Straight Shank Masonry Drill 6 x 100mm (Working Length 54mm)
N36-1174 Straight Shank Masonry Drill 6.5 x 100mm (No.12) (Working Length 54mm)
N36-1175 Straight Shank Masonry Drill 7 x 100mm (No.14) (Working Length 54mm)
N36-1176 Straight Shank Masonry Drill 8 x 120mm (Working Length 80mm)
N36-1180 Straight Shank Masonry Drill 8 x 400mm (Working Length 300mm)
N36-1178 Straight Shank Masonry Drill 10 x 120mm (Working Length 80mm)
N36-1184 Straight Shank Masonry Drill 13 x 400mm (Working Length 300mm)
N36-1185 Straight Shank Masonry Drill 16 x 300mm (Working Length 220mm)
N36-1186 Straight Shank Masonry Drill 20 x 400mm (Working Length 300mm)
