CorePlus Elite All Cut Multi-Material Diamond Blade

The CorePlus Elite All Cut Multi-Material Diamond Blade delivers Elite Endurance and Elite Performance in a diverse range of applications. Easily rises to the challenge and wins in all situations.

A precision-engineered, hardened, high-grade 65Mn manganese steel tensioned core ensures the blade runs true, whilst double laser welding technology reduces the risk of damaged segments. The alternating segment structure creates an efficient waste material release for a smooth cut with blistering speed and a fluid feel. The segments have the maximum concentration of ultra-grade nano and micro cube-octahedron diamond crystals meshed within the metal matrix bond. It also features a state-of-the-art, metallurgically engineered, high-performance and long-life bond formulation that ensures maximum durability and lifetime.

Manufactured to EN 13236 quality standard. oSa® certified to the highest level of quality and tested safety.

For cutting the following materials:

Asphalt
Asphalt Over Concrete
Blocks - Breeze
Blocks - Toplite
Blocks - Lignacite
Paviours - Clay
Paviours - Hard
Paviours - Medium Block
Clay - Pipes
Clay - Roof Tiles
Concrete - Hard Aggregates
Concrete - Paving Slabs
Concrete - Pipes
Concrete - Kerbs
Concrete - Tiles
Concrete - Cured
Concrete - Lintels
Concrete - Lintels Reinforced
Concrete - Limestone
Concrete - Green
Bricks
Bricks - Engineering
Bricks - Medium Facing
Bricks - Hard Facing
Gritstone
Sandstone - Medium
Sandstone - Hard
Marble
Slate
Slate - Hard
Cement Board
Roofing Tiles
Terracotta
Iron - Ductile
Cast Iron
Steel
Sheet Metal

Available in 230, 300 and 300mm diameters.

Mills Part Numbers

P09-0617 Diameter: 230mm (Bore: 22.23mm - Segment Height: 12mm - Segment Width: 2.6mm)

P09-0622 Diameter: 300mm (Bore: 20mm - Segment Height: 12mm - Segment Width: 2.8mm)

P09-0623 Diameter: 350mm (Bore: 25.4mm - Segment Height: 12mm - Segment Width: 3.0mm)
