Bend Duct Grey - 53.9mm Outside Diameter (Duct 56)

Emtelle duct bends for use with Duct 56 with an outside diameter of 53.9mm and inside diameter of 50mm.

Features

• Manufactured from virgin PVC-U polymer = 100% reliable performance.
• Duct Systems are manufactured to Industry Standard BSEN 61386.
• Solid wall construction, capable of being back-filled with “As Dug” materials where appropriate and not affected by sharp stone impingement.
• Smooth bore ensuring easier and safer installation of sub-ducts and cables owing to lower internal friction.

Available in the following sizes:

Bend Duct 22.5 Degrees Grey (350R)

Radius: 350mm

Pack of 60

-----

Bend Duct 45 Degrees Grey (Bend Duct 56B)

Radius: 150mm

Pack of 75

BT Openreach Ref: 095002

------

Bend Duct 90 Degrees Grey 53.9mm OD (House Bend 200R)

Radius: 200mm

Pack of 60

BT Openreach Ref: 090126

-----

Bend Duct 90 Degrees Grey 53.9mm OD (Long Bend Duct 56A)

Radius: 592mm

Pack of 15

BT Openreach Ref: 094929

Mills Part Numbers

S83-5065 Bend Duct 22.5 Degrees Grey 53.9mm OD - Pack of 60
S83-5066 Bend Duct 45 Degrees Grey 53.9mm OD (Bend Duct 56B) Pack of 75
S83-5067 Bend Duct 90 Degrees Grey 53.9mm OD (Bend Duct 56) Pack of 60
S83-5068 Bend Duct 90 Degrees Grey 53.9mm OD (Bend Duct 56A) Pack of 15
