Altrad Belle PCLX 32 Honda GX120 13in 3.2HP

Altrad Belle PCLX 32 Honda GX120 13in 3.2HP

Professional compaction plates with low Hand Arm Vibration and high performance compaction from the 13kN vibrator.

The Belle PCLX 32 is strong, robust, user-friendly and dependable forward plate compactor.

It features a tubular frame design to protect vulnerable components and has been engineered are withstand the rigours and demands of rental and contractor use alike.

Its contoured baseplate has been designed to make it not dig in when dragged or turned and to optimise speed and manoeuvrability, making it both easy to operate and control.

Although strong and robust, this high performance plate is comparatively lightweight thanks to its tubular frame construction. This is achieved without compromising its strength, performance, durability or reliability.

It is also equipped with multiple manual handling lift points, a conveniently located central lifting point and a detachable main handle for ease of movement and transportation. Despite being BIG on performance, it is compact enough to even fit in a standard car boot when their handle is folded.

The PCLX 32 is equipped with a powerful genuine Honda GX120 engine and a 13kN high performance oil filled vibrator which is fitted with top quality bearings for durability and reliability, designed to produce both maximum compaction and excellent travel speeds.

Low Hand-Arm Vibration design for longer safe usage times.
Powerful, reliable Honda GX120 petrol engine.
High performance 13kN vibration unit gives excellent compaction force and travel speeds.
Tubular frame designed to protect vulnerable components.
Baseplate designed for optimised speed and manoeuvrability.
Lightweight yet durable for easy transport.
Fits in a standard car boot when the handle is folded.
Fitted with manual handling points.
Engineered to be robust and durable for rental and heavy contractor usage.
Easy to operate and control, the baseplate does not dig in when dragged backwards or turned.
Optional, removable 12-litre water tank features a quick-release design.
Optional wheel kit to aid on-site transportation available.
Optional paving pad for block paving applications available.
Customer colour options available.

Technical Specifications:

Width (mm) 320
Operating Height (mm) 935
Storage Height (mm) 620
Engine Power (Hp / Kw) 3.2
Engine RPM 3850
Weight (kg) 64
Static Pressure (kg/m²) 416
Centrifugal Force (kN) 13
Frequency (Hz) 101 1
Max. Travel Speed (m/min) 20
Vibration level (m/sec²) 2.49
