Altrad Belle Hydraulic Breaker

Sturdy and reliable breaker featuring ultra dampened handles and designed for working together with the Altrad Belle Hydraulic Power Pack.

Features

Improved, lock-on, ergonomic handgrips.
Compatible with the range of ALTRAD Belle Hydraulic Power Packs.
Frequency and Blow Rates to achieve maximum productivity.
For use on a number of materials, from light brickwork to asphalt.
Delivered with 1/2” tail-hoses with 1/2” at-face couplings.
Hoses are removable for easy transportation and storage.
Can also be changed quickly if damaged.
Very reliable and simple to maintain = less servicing costs.

Available in the following models.

Specifications

Model BHB 23
Max Pressure (bar) 160
Hydraulic Flowrate (l/min) 20
Blows per Minute 1600
3-Axis Vibration (m/sec2) **11.97
Breaking Force (J) 65
Steel Size (mm) 25 x 108
Weight (kg) 23.5
Sound Power Level (dB LWA) 107

---------------

Model BHB25XS
Max Pressure (bar) 160
Hydraulic Flowrate (l/min) 20
Blows per Minute 1600
3-Axis Vibration (m/sec2 ) **6.5
Breaking Force (J) 55
Steel Size (mm) 32 x 160
Weight (kg) 25
Sound Power Level (dB LWA) 108

------------------------

Model BHB 27
Max Pressure (bar) 160
Hydraulic Flowrate (l/min) *20/30
Blows per Minute 1300 (20ltr)
Blows per Minute 2150 (30ltr)
3-Axis Vibration (m/sec2) **11.8 (20ltr)
3-Axis Vibration (m/sec2) **18.6 (30ltr)
Breaking Force (J) 85
Steel Size Hex (mm) 32 x 160
Weight (kg) 27
Sound Power Level (dB LWA) 108

These products may incur an additional carriage charge. Please contact sales for details.

Mills Part Numbers

P57-3840 Altrad Belle BHB23 Medium / Heavy Weight Hydraulic Breaker

P57-3999 Altrad Belle BHB25XS Low Vibration Hydraulic Breaker

P57-3841 Altrad Belle BHB27 Heavy Weight Hydraulic Breaker
