Altrad Belle Bulldog HPX01S Hydraulic Power Pack

An efficient, portable on site power source that is 12% more compact but with the same market leading performance. Comes with integrated Power On-Demand (POD) system and more powerful engine than the standard market equivalent.

Features

12% more compact but with the same market leading performance.
Small enough to be transported in estate cars and small vans.
Tilt-back protection frame allows for simple routine maintenance.
More powerful engine than standard market equivalent.
Fully protected oil filler complete with retaining chain.
Complete with integrated POD (Power On Demand) system which helps reduce carbon emissions & results in 50% less fuel usage.
Recoil protection system.
Low engine & hydraulic oil cut out protects tools & system pump.
Rigid & durable steel chassis and protection frame to prevent component damage.
Hose storage position and lifting-eye integrated into protection frame with fi tted wheels to aid on-site transportation.
Supplied with removeable braided Siamese hose set with high quality non-drip face couplings (pre-filled with Hydraulic Oil).
Removable hose sets aid transportation and storage and can be changed quickly if damaged.
Can be used with Altrad Belle BHB 25X, BHB 27X, BHB 12, BHB 23, BHB 25 & BHB 27 Hydraulic Breakers and Hydraulic Submersible Pumps.

Specifications

Ref HPX01S
Model Bulldog Honda GX270 Petrol
Engine Power 9.0 / 6.7 hp/kW
Hose Length 6.75 metres
Pressure 140 bar
Flow 20 litres per minute
Oil Tank Capacity 5.6 Litres
Fuel Tank Capacity 6.0 litres
Width 515mm
Height 620
Length 705mm
Weight 59.5kg
