1M Fibre Pigtail SM SC/APC OS2 G657A2 9/125 (White)

1M Fibre Pigtail SM SC/APC OS2 G657A2 9/125 (White)

OS2 Fibre optic pigtail suitable for common splicing applications supplied in a 1 metre length 900μm tight buffered fibre cable with a white jacket.

All assemblies are fully tested prior to delivery and supplied with test results.

Application

Telecom, CATV and LAN applications

On-site termination

Patch Panels, wall boxes, ODFs and splice cassettes, dome and inline splicing enclosure

Features

LSZH - Low smoke zero halogen, 900µm tight buffered fibre

Fibre conforms to or exceeds all relevant ISO/IEC, TIA/EIA and ITU standards

Fibre Specification

Attenuation (db / km) ≤ 0.32 @ 1310nm / ≤ 0.18 @ 1550m

Chromatic Dispersion (ps/nm=km)

1285 - 1340 ≥ -3.4 ≤ 3.4

1550nm ≤ 18

1625nm ≤ 22

Zero Dispersion Wavelength (nm) 1312 ± 22

Cable Specification

Crush N/100mm 500

Operating Temperature (°C)°C-20 to +60

Nominal Buffer Diameter μm 900+50

Max Tensile Load N 6

Connector Specification

IL Max/Master (db) (Acceptance) ≤ 0.25

Av./Random (db) ≤ 0.20

Return Loss ≥ 65
